Prime Hot Dipped Galvanized Steel Coils Sheet Prepainted Galvalume JIS SGCC SGCD

Certification : ISO TUV SGS BIS CE

Place of Origin : Shandong China

MOQ : 3Tons

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram,OA

Supply Ability : 5000Tons Per Months

Delivery Time : 5-15days depend on the quantity

Brand Name : TESTE

Packaging Details : With iron sheet to pack the steel sheet and pallet .Also make the shipping marks on each bundles.

Price : Negotiate

Product name : Galvanized Steel Sheet

Standard : ASTM，AISI，JIS，GB， DIN，EN

Type : Hot-dip galvanized

Width : 580~1250mm

Product Name : Alloy Steel Coil

High light : pipe

Contact Now

JIS SGCC/SGCD Hot-Dip Galvanized Steel Sheet
galvanized steel

Galvanized Steel Sheet is defined as a carbon steel sheet coated with zinc on both sides. Galvanized Steel Coil Importer produce galvanized steel with two main processes: continuous hot dip galvanizing and electro-galvanizing.

A zinc coating is one of the most effective and economical methods of protecting bare steel from a corroding environment. The zinc not only serves as a barrier between the steel and the environment, but it will also sacrifice itself to protect the underlying steel sheet. Sacrificial or galvanic protection occurs when two dissimilar metals are in contact and coupled with water and oxygen. Zinc corrodes preferentially to the iron in steel. This protection prevents corrosion of the steel at areas not covered with zinc. Thus, the spread of corrosion from cut edges, drill holes, etc. is minimized.

COATING

Type Coating mass(g/m2) Plate thickness(mm) Width(mm)
Hot Dip Galvanized steel Hot-dip galvanealed steel sheet and coil/strips 30~120 0.5~4.5 580~1250
Hot-dip galvanized steel sheet and coil/strips 60~600 0.23~6.0 580~1250
Hot-dip zinc-aluminum-magnesium-silicon alloy coated steel sheet and coil/strips 60~275 0.27~9.0 580~1250
Hot-dip aluminum coated steel sheet and coil/strips 40~160 0.3~2.5 580~1250
Electrogalvanized steel Electrolytic zinc coated steel sheet and coil/strip 10~40 0.4~2.3 580~1250
Electrolytic zinc-nickkel coated steel sheet and coil/strip 10~40 0.4~2.3 580~1250

GRADE

DX51D+Z

DX52D+Z

DX53D+Z

S280GD+Z

S350GD+Z

S550GD+Z

DX51D+AZ

DX52D+AZ

DX53D+AZ

S280GD+AZ

S350GD+AZ

S550GD+AZ

DX51D+AZM

DX52D+AZM

DX53D+AZM

S280GD+AZM

S350GD+AZM

S550GD+AZM

SGHC

SGH400

SGCC

SGCH

SGCD

SGC400
